3311F-16 DC Electronic Load 80V , 70A , 350W
80V , 70A , 350W
Model :
3311F-16
- Each 3310F Series module has its own control and display panel, CC/CR/CV/CP/Dynamic modes, plug in 3300F with 150 sets Store/Recall memory which provides load set-up more efficiently，also can be controlled intranet via RS232、Ethernet、USB and GPIB interface.
- SHORT time setting and SHORT_VH, SHORT_VL setting function，also can measure Short Voltage and Current.
- Dynamic can be simulated under CC, CP mode. The current Rise/Fall slew rate can be adjusted individually and there is an external signal input so that load can have a simulated Arbitrary Waveform.
- The additional OCP 、OPP test function operated by both mainframe and module that will be more efficiency and accuracy on OCP, OPP testing.
- Programmable Load ON/OFF voltage, GO/NG meter check, Voltage meter display “ + “ or “ – “ is selectable and 150 sets Store/Recall larger memory is much advance feature for each different application.
- 150 sets test parameter and status storage function can call the storage memory real time in accordance with the auto sequence requirement.
- 5 digital V / A / W Meter.
- High-speed measurement and communication transmission.
- V.A.W. values can be displayed simultaneously.
- Large LCD Display、setting values can be adjusted by rotary knob or push button.
- OCP 、 OPP test function.
- Must be configured in 3302F〔single channel mainframe〕3302F mainframe provides the NTC simulation test function（Option）、3305F〔two channels mainframe〕or 3300F〔four channels mainframe〕and the mainframe with 150 sets Store / Recall memory.
- Power ON status value can be set.
- Flexible CC. CR, CV, CP, Dynamic and Short operation modes.
- SHORT time setting and SHORT_VH, SHORT_VL setting function.
- Protections against V, I, W, and °C.
- Voltage meter display the polarity positive（” ＋ ”）or negative（” － ”）is selectable.
- SYNC. Load ON function.
- Optional Interface : GPIB、RS232、USB、LAN.
- Support MPPT CC, CR, CV test function for solar panel
- Function test for BMS protection board is provided (option)
- New waveform generator plug in model 9923 adds user programmable battery discharge current waveform simulation to Prodigit DC Loads
- Voltage / Current source
- SMPS transient response
- Current limit testing and battery emulation
- Battery charger
- Battery discharge
- R&D, Quality Control
- ATE system
- Production testing
